Application
Suitable for the riveting process of various casting and welding brake shoes and brake linings.
Features
This machine adopts the latest patented technology to realize the functions of automatic throwing rivets,automatic rotation indexing,automatic riveting;Automatic rivet detection, automatic pressure detection,automatic detection and automatic display of the riveting force for each hole;Stable and reliable quality,and high production efficiency. It is suitable for the heavy duty brake shoes with 2 or 4 rows of holes spacing on the market. One person can operate two machines, reducing the labor intensity of employees,and is the best equipment for the stable quality and labor cost of the brake shoe riveting industry.
Technical Parameters
| Item | Parameter |
| Max radius of riveting shoes outer arc | R215mm |
| Min outer arc radius | R180mm |
| Processing width range | 150mm-222mm,adjacent minimum angle:any |
| Riveting force | 0-25000N (related to the diameter of the rivet) |
| Riveting speed | 2 seconds per hole net riveting time/hole (associated with the hole arrangement);so usually finishing one shoe need 35 seconds(net riveting time) |
| Hydraulic station motor power | 5.5KW |
| Pressure | 0-8MPa |
| Indexing servo motor power | 1.5KW |
