Purpose
There are two primary forming processes for automotive drum brake shoes:First one, single-cavity or multi-cavity single-piece forming;Second one, production of connected long shoe blanks, which are then cut into individual pieces according to required width.This machine is a special cutting equipment designed for cutting connected long shoe blanks.
Technical Parameters
- Overall dimensions: 1500×1000×1300 mm
- Cutter spindle motor: 1 unit, 18.5 KW, 2930 rpm
- Shoe feeding motor: 1 unit, 0.37 KW, 1500 rpm
- Feeding wheel speed (stepless speed regulation): 0–4.48 rpm
- Cutter spindle speed: 2371 rpm or 3621 rpm (two interchangeable pulleys)
- Dimensions of cuttable long shoe blanks:
① Maximum length: 800 mm
② Inner arc radius: R150–R205
③ Brake shoe thickness: ≤20 mm
④ Simultaneous cutting quantity: On-demand
